Electrical insulation mat for 11kv data sheet:
| Thickness | Length | Weight | Withstand Voltage ( KV ) |
|---|---|---|---|
| 3mm | 10m/roll 20m/roll or as your request | 4.5KGS/M² | 10KV |
| 4mm | 10m/roll 20m/roll or as your request | 6KGS/M² | 10KV |
| 5mm | 10m/roll 20m/roll or as your request | 7.5KGS/M² | 10KV |
| 6mm | 10m/roll 20m/roll or as your request | 9KGS/M² | 10KV |
| 3mm | 10m/roll 20m/roll or as your request | 4.5KGS/M² | 20KV |
| 4mm | 10m/roll 20m/roll or as your request | 6KGS/M² | 20KV |
| 5mm | 10m/roll 20m/roll or as your request | 7.5KGS/M² | 20KV |
| 6mm | 10m/roll 20m/roll or as your request | 9KGS/M² | 20KV |
| 7mm | 10m/roll 20m/roll or as your request | 10.5KGS/M² | 30KV |
| 8mm | 10m/roll 20m/roll or as your request | 12KGS/M² | 30KV |
| 9mm | 10m/roll 20m/roll or as your request | 13.5KGS/M² | 40KV |
| 10mm | 10m/roll 20m/roll or as your request | 15KGS/M² | 40KV |
| 11mm | 10m/roll 20m/roll or as your request | 16.5KGS/M² | 40KV |
| 12mm | 10m/roll 20m/roll or as your request | 18KGS/M² | 50KV |
| 13mm | 10m/roll 20m/roll or as your request | 19.5KGS/M² | 50KV |
| 14mm | 10m/roll 20m/roll or as your request | 19.5KGS/M² | 50KV |
Electrical rubber mat 11kv description:
Electrical insulation mat for 11kv is a crucial component in ensuring the safety of electrical workers and preventing electrical accidents. These mats serve as a protective barrier between workers and the potentially dangerous electrical equipment they are working with. The 11kv rating indicates that these mats are specifically designed to withstand high voltage levels, providing reliable insulation and protection.
By placing these mats on the ground in areas where electrical maintenance or repair work is being carried out, workers can reduce the risk of electric shock or injury. These mats are made from durable and electrically non-conductive materials, such as rubber, to effectively prevent the flow of electricity.
Additionally, they may include features like anti-skid surfaces to provide further safety. The correct usage of electrical insulation mats for 11kv is of utmost importance to ensure a safe working environment for electrical workers, minimizing the chances of accidents and injuries.
